Machine Name: Automatic Flatbed Die-Cutting Machine for Corrugated Cardboard and Plastic Cardboard, Model CM1712
Application Range: Corrugated cardboard sheets F, B, C, A, AB flute
Maximum Sheet Size: 1700mm x 1200mm
Minimum Sheet Size: 600mm x 400mm
Maximum Die Size: 1680mm x 1180mm
Maximum Wood Die Size: 1840mm x 1230mm
Minimum Wood Die Size: 620mm x 530mm
Thickness of Wood Die: 16-18mm
Die Height: 23.6mm
Die Pressure Adjustment Range: 23.6mm - 22.6mm
Platen Stroke: 70mm
Maximum Die-Cutting Speed: 3000 sheets/hour
Gripper Margin: 10mm
Maximum Die-Cutting Pressure: 350 tons
Required Power: 28.48kW (Main motor power 22kW, inverter control, rated 80.0A)
Primary Power Supply: 200V three-phase 60Hz (50Hz)
Primary Air Source: 0.9MPa
Air Consumption: 0.5MPa 10 L/min
Machine Dimensions: 8320mm x 5005mm x 2285mm (Length x Width x Height) (including worktable)
Machine Total Weight: 35 tons
Paper Discharge Direction: Same as the paper feeding direction, as viewed from the feeding side
Operator Position: Left side as viewed from the feeding side (right-hand operation is optional)
